INFRARED SENSING [IR]

Thermal Imaging & Radiometrics

Calibrated infrared imaging to map moisture pathing, structural heat loss, and electrical hotspots with sub-degree accuracy.

ENTERPRISE DUAL-SPECTRUM 640T • COMMERCIAL FACILITY // DUAL-BAND SURVEY

RGB VISUAL [50MP CMOS]

IRONBOW [RADIOMETRIC]

MAX: 149.5°C (301.1°F)

MIN: 67.6°C (153.7°F)

MEAN: 76.8°C (170.2°F)

84.2°C | 183.6°F

↔

Target Span 67.6°C — 149.5°C

Scene Mean 76.8°C (170.2°F)

Sensor Core 4.2°C (NETD ≤30mK)

Atmosphere / Refl 2.6°C / 2.5°C

Emissivity / RH ε=0.95 / 33% RH

GPS Telemetry

39.125°N, -94.813°W PROTECTED

[ Drag slider handle horizontally to compare bands ]

Enterprise Radiometric Core

Dual-Spectrum Reveal

Directly comparing the calibrated 50MP visual RGB channel with the 640×512 radiometric thermal feed over a commercial facility roof inspection. Sub-surface moisture loops, insulation breaches, and electrical overloads invisible to the human eye become instantly quantifiable.

Severe Thermal Anomaly Detected: 149.5°C (301.1°F)

Localized +72.7°C differential above baseline roof plane isolated at coordinates (X: 589, Y: 446). Indicates severe equipment thermal bridging or exhaust degradation requiring immediate physical verification.

Verified Sensor & Survey Telemetry

Telemetry.Feed

PAYLOAD: Calibrated 640T Core

THERMAL: 640×512 (12μm VOx)

SENSITIVITY: ≤ 30 mK NETD

OPTICAL RGB: 50MP 1/1.28" CMOS

SPECTRAL BAND: 8 – 14 μm LWIR

CALIBRATION: ±2°C Accuracy

TEMP SPAN: 67.6°C – 149.5°C

MEAN TEMP: 76.8°C (170.2°F)

REFLECT/ATM: 2.5°C / 2.6°C

EMISSIVITY: ε = 0.95 (33% RH)

GPS: 39.125111° N, -94.812973° W PROTECTED • ALT: 328m ASL

Thermal Use Cases

Calibrated thermal outputs solve structural and electrical issues across diverse sectors.

Moisture Scans

Telemetry.Feed

💧

Roof Membrane Leaks

Locate sub-surface leaks on commercial flat roofs. Trapped water acts as a thermal battery, glowing hot at sunset.

Solar Fields

Telemetry.Feed

☀️

Cell & Diode Auditing

Perform sweeps over multi-acre solar installations. Pinpoint hotspots, string shortages, and dirty cells instantly.

Electrical Utilities

Telemetry.Feed

⚡

Switchgear Overload

Audit substations and overhead high-voltage components to locate high-resistance faults before failure occurs.

Schedule a Thermal Scan

Successful infrared scans require stable environmental windows (zero wind, specific cloud cover, and rapid sunset cooling). Connect to schedule.

Request Thermal Assessment
